Blue Sea Terminal Fuse (60 Amp / Gold)

Blue Sea Terminal Fuse (60 Amp / Gold)

SKU:8-25178

Regular price £26.01
Regular price £32.95 Sale price £26.01
Sale Sold out
Tax included. Shipping calculated at checkout.

Blue Sea 5178 terminal fuse (MRBF - Marine Rated Battery Fuse) rated at 60A.
High Interrupt Rating satisfies ABYC requirements for DC Main circuit protection on large battery banks
Clear window - blown visual indication
Colour coded for each amperage
Regulatory - Terminal Fuses
Meets SAE J1171 external ignition protection requirements IP66 - protected against powerful water jets ABYC E-11.12.1.1. 1. Each ungrounded conductor connected to a battery charger, alternator, or other charging source, shall be provided with over current protection within a distance of seven inches (175mm) of the point of connection to the DC electrical system or to the battery.
Maximum Voltage: 58V DC
Interrupt Capacity: 10000A @ 14V DC, 5000A @ 32V DC, 2000A @ 58V DC
Weight 0.06lb (0.03 kg)

Please note: this fuse requires the use of Terminal Fuse Blocks 5191 or 2151 - do not mount the fuse directly to the battery terminal.
