Blue Sea L-Series Solenoid Switch (12V & 24V / 250A)
Blue Sea L-Series Solenoid Switch (12V & 24V / 250A)
SKU:8-29012
Couldn't load pickup availability
Blue Sea 450 Ampere compact solenoid 9012 offers remote switching for applications with limited space and no requirement for manual control.
Hermetically sealed contacts
Activated by an ON-OFF switch mounted remotely
Integrated coil control minimizes heating and amperage draw
Mount in a dry location
Control Circuit Voltage: 9-36V DC (12/24V nominal)
Control Circuit Connection: 20 AWG Tinned Wire
Contact Voltage: 800V DC
Amperage Operating Current continuous: 0.13A @ 12 V, 0.07A @ 24 V
Amperage Operating Current when changing state: 3.6A
Terminal Stud: M8 (accepts 5/16" terminals)
Terminal Stud Torque: 90 in-lb (10.17 Nm) max
Continuous Rating: 250A Using 1/0 Wire Size, 300A Using 2/0 Wire, 400A Using 4/0 Wire, 450A Using 2x (2/0) Wire
Intermittent Rating (5 min): 275A Using 1/0 Wire Size, 400A Using 2/0 Wire, 500A Using 4/0 Wire, 600A Using 2x (2/0) Wire
Cranking Rating 30 sec: 1,000A with 1/0 cable
Contact Form: SPST-NO
Inrush Rating 0.25 sec (10 repeats): 2000A
Mounting Screw: #10 or M5
Stud Material: Stainless Steel
Terminal Stud Length: 0.66" (16.76 mm)
Weight: 1.00lb (0.45 kg)
Approvals: CE, Ignition Protected, IP67, SAE J1171 Marine, UL 508
