Blue Sea 285 Panel Mount Circuit Breaker (120A)
Blue Sea 285 Panel Mount Circuit Breaker (120A)
SKU:8-27088
Couldn't load pickup availability
Blue Sea 7088 panel mount circuit breaker provides medium duty circuit protection for 120 Amp loads when switching and circuit protection are both required.
- 285 Series
- Trip-free - cannot be held closed after trip
- Visible reset lever shows open condition
- Drop-in replacement for 185-Series Circuit Breakers
Regulatory:
- CE marked
- Meets SAE J1171 external ignition protection requirements, †AIC ratings achieved using SAE J1625
IP67 - protected against immersion up to 1 meter for 30 minutes
Specifications:
Interrupting Capacity: 3000A at 48V DC
Vmxo: 48V DC
Operating Temperature: -40 C min to +85 C max
Type: Thermally Responsive Bi-Metal Blade
Class: Type III Switchable/Manual Reset - Trip Free
Terminal Stud: M6
Terminal Stud torque: 50 in-lb
Mounting: 1/4" Screw
